Manual Dimmer

Back to list

APPLICATION

  • Model No

    HT-DIM-015D

  • AC input

    230VAC
    120VAC
    50/60Hz Singel Phase

  • Input Current

    17A Max

  • Safety

    Anti 6KV Lightning Surge
    Dim to 0%, Dry Switch-Contact

  • Performance

    Harmonic Current Inhibition

  • Optimal Brightness level

    0-100%

  • Five Protections

    OVP (Over Voltage Protection)、UVP( Under Voltage Protection)、OPP (Over Power Protection)、OTP (Over Temperature Protection)、OCP (Over Current Protection/ Short Circuit Protection)

  • Dimensions

    275*154*66mm

  • Weight

    1.8kg

  • Permitted ambient temperature

    -20℃-50℃

  • Storage temperature

    -30℃-80℃

  • IP Grade

    IP44

  • External Control

    0-10V
